WNR·SWNR

500-10000VA, 100-260Vac, 140-260Vac

Meet the WNR and SWNR series, KEBO's flagship Relay Type Automatic Voltage Regulators, designed to be the guardians of your electrical stability. Whether you're running a small home office or a large commercial operation, these regulators ensure that your devices receive a consistent and reliable power supply.

Consulting

Home

1. Optional Display Upgrade

The SWNR series offers an optional integrated LED digital display for advanced monitoring and diagnostics.

2. Enhanced Cooling System

The smart fan system is designed to automatically adjust its operation based on the internal temperature, ensuring consistent performance.

3. Flexible Input Range

The ability to handle a wide range of input voltages (100-260Vac/140-260Vac) makes these regulators versatile for different regions and power conditions.

4. Advanced Protection Mechanisms

In addition to standard protections, these regulators offer adjustable output delays for short circuits, providing customized protection settings.

Specification

Model	WNR-500VA	WNR-1000VA	WNR-1500VA	WNR-2000VA	WNR-3000VA	WNR-5000VA	WNR-8000VA	WNR-10000VA
Model	SWNR-500VA	SWNR-1000VA	SWNR-1500VA	SWNR-2000VA	SWNR-3000VA	SWNR-5000VA	SWNR-8000VA	SWNR-10000VA
Power	300W	600W	900W	1200W	1800W	3000W	4800W	6000W
Technology	Zero Cross Switching Technology & Digital CPU Control Circuit & Delay Countdown System
Transformer	Toroidal Transformer
Input Voltage	100-260Vac/140-260Vac,50/60Hz
Output Voltage	220V/230V,±10% or 8%
Efficiency	98%
Phase	Single Phase
Display	WNR Series: Classical Dual LED Digital Display				SWNR Series: New Integrated LED Digital Display
Cooling	SmartFan(Automatic Startup at 65°C)
Protection	High Voltage/Low Voltage (Optional)/Overheat/Overload/Short Circuit/6s or 180s Output Delay
Certification	CE(LVD+EMC)
Unit weight/N.w.	2.8 kgs	3.5 kgs	4.3 kgs	4.7 kgs	8.5 kgs	10.2 kgs	14.8 kgs	16.9 kgs
Giftbox Size(mm)	283225182	283225182	335225182	335225182	430222198	430222198	435290228	435290228
Carton Size(mm)	465293385(4)	465293385(4)	460420417(4)	460420417(4)	N/A	N/A	N/A	N/A
